Colander quick deploy

Welcome to Colander quick deploy.

Here you'll find all the necessary resources to get the entire Colander stack up and running as quickly as possible (or just the components you're interested in).

Requirements

You'll need docker and docker compose.

Download

You can download colander quick deploy from here.

This is licensed under GPLv3. You can find the sources on our Github repository (the archive above is based on colander-ansible/docker folder).

Using docker to deploy the PTS stack.

You can start some of the tools (using docker compose -f compose-xxx.yml up -d command like described below) or you can start the whole stack by just going with docker compose up -d

Before starting

Most of the settings are pre-configured with sanely safe defaults. Some others are required before starting.

To boostrap your environment, please run compose-init.yml first:

docker compose -f compose-init.yml up -d

This will bootstrap a minimal .env file which will be used by docker. It contains some secrets randomly generated for you.

If you want more control over how things are configured, please take a look at .env.example. There, you'll find all the settings available with some comments that should help you in getting the hands on PTS' configuration.

Start colander only

docker compose -f compose-colander.yml up -d

By default, colander should be available at:

• http://localhost:5000
• https://colander.local:4443 (if you put colander.local as additional hostname on line starting by 127.0.0.1)

Start threatr only

docker compose -f compose-threatr.yml up -d

By default, threatr should be available at:

• http://localhost:5001
• https://threatr.local:4443 (if you put threatr.local as additional hostname on line starting by 127.0.0.1)

Start mandolin only

docker compose -f compose-mandolin.yml up -d

By default, mandolin should be available at:

• http://localhost:5002
• https://mandolin.local:4443 (if you put mandolin.local as additional hostname on line starting by 127.0.0.1)

Start cyberchef only

docker compose -f compose-cyberchef.yml up -d

By default, mandolin should be available at:

• http://localhost:5003
• https://cyberchef.local:4443 (if you put cyberchef.local as additional hostname on line starting by 127.0.0.1)

Starting a "à la carte" stack (multiple tools)

Of course, you can pick more than one tool by giving the corresponding compose file as a value of -f argument of the docker compose CLI:

docker compose -f compose-colander.yml -f compose-threatr.yml up -d

Starting the whole stack

The following command should get you up and running fairly quickly (by default, you may be able to start straight away. But in some case you may need to adjust the .env file, so take a look to it. It should be self-explanatory):

docker compose up -d

# or the following if you cannot obtain a valid letsencrypt certificate because of your context/requirements (it
# will generate a self signed certificate ./data/traefik/certs/self-signed/cert.pem ; which you
# can add to your Pirogue's operating system trust store) so your pirogue will be able to connect to colander using
# https and this certificate (see below)
# This compose file will also expose Traefik's dashboard on port http://localhost:8080
docker compose -f compose-dev.yml up -d

This will :

• create a self signed certificate (allowing you to use pirogue tooling to connect to colander without requiring a certificate issued by a Certificate Authority).
• start the whole stack (colander, threatr, mandolin, etc.)
  • you'll get access to:
    • Colander
    • Threatr
    • Cyberchef
    • Traefik dashboard

Note: those tools can also be accessed through their respectie hostnames (if you add them to your /etc/hosts file):

• Colander
• Threatr
• Cyberchef
• Traefik dashboard

Creating a Threatr integration for your colander

Below are the quick steps to connect your Colander to yoyr Threatr (this is also documented on our website):

• 1. Creating super users on both tools:

  docker compose -f compose-dev.yml exec colander-front /entrypoint python manage.py createsuperuser
  docker compose -f compose-dev.yml exec threatr-front /entrypoint python manage.py createsuperuser


• 2. Creating a simple user colander-user in threatr (via https://threatr.local/admin)
• 3. Creating an API key for colander-user in threatr (via https://threatr.local/admin)
• 4. Adding a Backend Credential in threatr with the following value (replace thetoken by the token you just created in threatr): { "api_key": "thetoken"}

note: You can also run docker compose up -d but you'll not get access to Traefik's dashboard nor generate a self signed certificate. compose.yml is the base file can be used as a base for production deployments. compose-dev.yml overrides some of the service definitions of the compose.yml.
